Garrett ATX with NEW 11″x13″ Mono Closed Search Coil: Comprehensive Guide

Introduction

The Garrett ATX with the new 11″x13″ Mono Closed Search Coil is a highly advanced metal detector. Designed for professional treasure hunters and prospectors. Known for its rugged build and superior detection capabilities. The ATX is perfect for extreme environments. including heavily mineralized ground and underwater exploration. This guide covers everything you need to know about. The Garrett ATX with the new search coil, including its features, specifications, how to use it, and tips for optimal performance.

Features

Advanced Pulse Induction Technology

The Garrett ATX utilizes advanced pulse induction (PI) technology. Which is highly effective in detecting metals in mineralized soils and saltwater environments. This technology provides greater depth detection and stability. Making it ideal for challenging conditions.

New 11″x13″ Mono Closed Search Coil

The new 11″x13″ Mono Closed Search Coil offers enhanced detection depth and sensitivity. Especially for smaller and deeper targets. Its closed design provides better ground coverage and reduces snagging in rough terrain.

Rugged and Waterproof Design

The ATX is built to withstand harsh conditions, with a durable, military-grade construction. It is fully submersible up to 10 feet (3 meters), making it suitable for underwater detecting in rivers, lakes, and shallow coastal waters.

Adjustable Ground Balance

The detector features an adjustable ground balance system. That compensates for varying soil conditions. This capability enhances detection accuracy and minimizes false signals caused by mineralized ground.

Multiple Search Modes

The Garrett ATX offers multiple search modes, including Motion and Non-Motion modes. These modes provide flexibility for different detecting environments and target types. Ensuring adaptability to various conditions.

Iron Check

This feature helps distinguish between ferrous (iron) and non-ferrous metals. Allowing users to ignore unwanted iron targets and focus on valuable finds. It can be easily activated with a single button press.

Enhanced Audio Indications

The ATX provides enhanced audio indications. Including multiple audio tones for different target types and signal strengths. This feature helps users better interpret the signals and identify targets more accurately.

Easy-to-Use Interface

The ATX is equipped with a user-friendly interface, featuring intuitive controls and a clear LCD screen that displays. Essential information such as target signal strength, ground balance settings, and battery status.

Specifications

• Operating Frequency: 730 pulses per second, adjustable

• Weight: 6.9 pounds (3.13 kg)

• Battery Life: Up to 10 hours with standard AA batteries

• Search Modes: Motion, Non-Motion, Iron Check

• Waterproof Rating: Submersible up to 10 feet (3 meters)

• Coil Size: 11″x13″ Mono Closed Search Coil

• Ground Balance: Adjustable

How to Use the Garrett ATX Metal Detector

Assembly

1. Attach the Coil: Connect the new 11″x13″ Mono Closed Search Coil to the lower shaft, ensuring it is securely fastened.

2. Adjust the Shaft: Extend or retract the shaft to a comfortable length and lock it in place.

3. Connect the Control Box: Attach the control box to the upper shaft and secure the cable.

Powering On and Calibration

1. Insert Batteries: Ensure the AA batteries are fully charged and inserted correctly.

2. Power On: Press the power button to turn on the detector.

3. Ground Balancing: Perform ground balancing by following the instructions on the LCD screen. Adjust the settings to match the current soil conditions for optimal performance.

Search Techniques

1. Sweep the Coil: Move the coil in a slow, steady motion, keeping it parallel to the ground.

2. Overlap Swings: Ensure your swings overlap slightly to cover the area thoroughly.

3. Responding to Signals: When a target is detected, use the pinpoint mode to locate the exact position of the object. Dig carefully to retrieve the item.

Tips for Effective Metal Detecting

Research Your Location

Research potential detecting sites before heading out. Areas with historical significance or known for valuable. Deposits increase your chances of finding treasures.

Start with Default Settings

Begin with the detector’s default settings to get a feel for its responses. As you become more familiar with the detector, adjust the sensitivity and discrimination settings as needed.

Use Headphones

Headphones help you hear faint signals that might be missed with the built-in speaker. They also reduce distractions from ambient noise and save battery life.

Regular Maintenance

Keep your detector in good condition by cleaning the coil and control box after each use. Check for loose connections and ensure the battery is charged. Regular maintenance extends the lifespan of the detector.

Common Issues and Troubleshooting

False Signals

False signals can occur due to high mineral content in the soil or interference from nearby metal objects. Adjust the sensitivity and perform ground balancing to reduce false signals.

Poor Depth Detection

If the detector is not detecting objects at depth, check the coil connection and ensure the battery is fully charged. Using the all-metal mode can also improve depth detection.

Unstable Readings

Unstable readings may be caused by a loose coil or cable. Secure all connections and ensure the coil is not moving excessively during operation.

Conclusion

The Garrett ATX with the new 11″x13″ Mono Closed Search Coil is a powerful and reliable tool for treasure hunters and prospectors. Its advanced features, combined with ease of use, make it suitable for both novice and experienced users. By following the tips and guidelines provided in this guide. You can maximize your chances of making valuable. Discoveries and enjoy a rewarding metal detecting experience. Happy hunting!

Personal Experience

I have Personally used this detector. It gives you a good depth into the ground. it is a very strong detector it doesn’t matter if dropped it is made of good quality it also gives you a good drop. Also gives you warranty. Initially it gives you little problem to operate but once you get the hang of it then it becomes very easy. for you first I learned it my self and then it It is very easy to use and Good metal detector on the ground.
